Xerox WorkCentre 4265 Service Manual

January 2016
7-63
WorkCentre 4150/4250/4260WorkCentre 4150/4250/4260WorkCentre Work-
PWB Connectors
Wiring Data
HVPS (4265)
Location: PL 1.20
Figure 28 HVPS (4265)
Main PWB (4265)
Location: PL 1.20
NOTE: The test points for the 4265 Main PWB are located in Figure 30.
Figure 29 Main PWB (4265)
CN3 CN4
CN1
CN2
1
1
CN5
CN39 CN11
CN1
CN33
CN26
CN41
CN34
CN24
CN25
CN42
CN35
CN9
CN18
CN13
CN2
CN22
CN15
CN28
CN27
CN29
CN19
CN21
CN31
CN14
1
1
1
1
1
1
1
1
1
1
1
1
1

Xerox WorkCentre 4265 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax, Email
Print Resolution (Max)	Up to 1200 x 1200 dpi
Memory (Standard)	2 GB
Memory (Maximum)	2 GB
Connectivity	10/100/1000Base-T Ethernet, USB 2.0
Paper Output	250 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Media Sizes Supported	Legal, Letter
Mobile Printing	Apple AirPrint
Duplex Printing	Automatic
Display	7-inch color touchscreen
