Xerox WorkCentre 4265 Service Manual

January 2016
1-7
WorkCentre 4150/4250/4260WorkCentre WorkCentre 4150/4250/42604150/
SCP 5
Service Call Procedures
HFSI
The High Frequency Service Items are shown in Table 4, Table 5 and Table 6. To change HFSI
settings, refer to GP 16 High Frequency Service Items. Refer to the relevant table:
• Table 4 WorkCentre 4150
• Table 5 WorkCentre 4250/4260
• Table 6 WorkCentre 4265
NOTE: The recommended life for new component installation is 90% of component life.
Table 4 WorkCentre 4150
Item Component Description
Recommended
life for new
component
installation
(90% of
component
life)
Parts list
reference
T1 Feeds Roll assembly
(pick-up roll,
feed roll,
retard roll)
All sheets fed from tray 1
after last HFSI reset.
180k feeds PL 7.15 Item 20
PL 8.10 Item 12
T2 Feeds Roll assembly
(pick-up roll,
feed roll,
retard roll)
All sheets fed from tray 2
after last HFSI reset.
180k feeds PL 7.25 Item 11
PL 8.10 Item 12
T3 Feeds Roll assembly
(pick-up roll,
feed roll,
retard roll)
All sheets fed from tray 3
after last HFSI reset.
180k feeds PL 7.25 Item 11
PL 8.10 Item 12
T4 Feeds Roll assembly
(pick-up roll,
feed roll,
retard roll)
All sheets fed from tray 4
after last HFSI reset.
180k feeds PL 7.25 Item 11
PL 8.10 Item 12
Bypass Rub-
ber Pad Life
Page
Bypass tray
retard pad
The total bypass tray
feeds after the last HFSI
reset.
40k feeds PL 8.20 Item 4
DADF Rub-
ber Pad Life
Page
DADF retard
pad
The total DADH feeds in
all modes after the last
HFSI reset.
45k feeds PL 5.20 Item 12
DADF Roller
Life Page
DADF feed roll
assembly
The total DADH feeds in
all modes after the last
HFSI reset.
180k feeds PL 5.15 Item 5
Fuser Unit
Life Page
Fuser assem-
bly
The total sides of copies
and prints after the last
HFSI reset.
180k impres-
sions
PL 10.25 Item 1
Heat Roll Life
Page
Fuser heat
roller assem-
bly
The total sides of copies
and prints after the last
HFSI reset.
180k impres-
sions
PL 10.26 Item 12
Pressure Roll
Life Page
Fuser pres-
sure roller
The total sides of copies
and prints after the last
HFSI reset.
180k impres-
sions
PL 10.26 Item 23
Transfer Roll
Life Page
Transfer roll The total sides of copies
and prints after the last
HFSI reset.
80k impressions PL 7.35 Item 19
Toner Car-
tridge Life
Page (see
NOTE)
Toner car-
tridge
The total sides of copies
and prints after the last
HFSI reset.
10k (starter
module)/20k
impressions
PL 9.10 Item 2
Developer
Cartridge Life
Page (see
NOTE)
Xerographic
module
The total sides of copies
and prints after the last
HFSI reset.
55k impressions PL 9.10 Item 1
Table 5 WorkCentre 4250/4260
Item Component Description
Recommended
life for new
component
installation
Parts list
reference
T1 Feeds Roll assembly
(pick-up roll,
feed roll,
retard roll)
All sheets fed from tray 1
after last HFSI reset.
230k feeds PL 7.15 Item 20
PL 8.10 Item 12
T2 Feeds Roll assembly
(pick-up roll,
feed roll,
retard roll)
All sheets fed from tray 2
after last HFSI reset.
230k feeds PL 7.25 Item 11
PL 8.10 Item 12
T3 Feeds Roll assembly
(pick-up roll,
feed roll,
retard roll)
All sheets fed from tray 3
after last HFSI reset.
230k feeds PL 7.25 Item 11
PL 8.10 Item 12
T4 Feeds Roll assembly
(pick-up roll,
feed roll,
retard roll)
All sheets fed from tray 4
after last HFSI reset.
230k feeds PL 7.25 Item 11
PL 8.10 Item 12
Bypass Rub-
ber Pad Life
Page
Bypass tray
retard pad
The total bypass tray
feeds after the last HFSI
reset.
40k feeds PL 8.20 Item 4
Table 4 WorkCentre 4150
Item Component Description
Recommended
life for new
component
installation
(90% of
component
life)
Parts list
reference

Xerox WorkCentre 4265 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax, Email
Print Resolution (Max)	Up to 1200 x 1200 dpi
Memory (Standard)	2 GB
Memory (Maximum)	2 GB
Connectivity	10/100/1000Base-T Ethernet, USB 2.0
Paper Output	250 sheets
Scan Resolution (Optical)	Up to 600 x 600 dpi
Fax Speed	33.6 Kbps
Media Sizes Supported	Legal, Letter
Mobile Printing	Apple AirPrint
Duplex Printing	Automatic
Display	7-inch color touchscreen
