Scan to SMB Setup
Xerox WorkCentre 7132 System Administration Guide 135
Procedure for Scan to FTP
1. On the control panel, select [Scan to FTP].
2. Enter all the information required. See the User Guide for more detailed
information.
3. Load a sample document into the document feeder.
4. Press the <Start> button on the machine.
5. Logon to the FTP server. Navigate to the directory path (repository) that was set
up earlier on the server. Your scanned document can be found in the specified
directory.
NOTE: If Kerberos authentication (remote authentication) has been enabled, a
separate login screen appears when the Scan to FTP feature is selected. Documents
are not scanned in unless the Kerberos server authenticates user access.
Scan to SMB Setup
Files can be scanned on the multifunction machine and routed on to a server or a client
using SMB protocol. Directory structures (repositories) need to be created on the
server to hold the scanned documents.
Prerequisites for Scan to SMB Setup
1. Confirm that an existing operational network utilizing TCP/IP is available.
2. SMB Server exists and is running.
3. Repository (folder) needs to be created on the SMB server to hold the scanned
document.
4. Confirm that the following ports are enabled:
1) TCP/IP Port
2) SMB Port
Data to Set Up Scan to SMB
Install
Requirement
Comments
Server IP address Required This is the IP address of the SMB server.
Server Shared Name Required This is the name assigned to the shared
folder on the SMB server.
Repository – directory path, where
the document will be stored on the
SMB server
Required This is the location or path of the directory for
saving scanned documents.
