Chapter 5: MicroBlaze Instruction Set Architecture
put
Put to stream interface
naput
rA, FSLx
put data to link x
n = non-blocking
a = atomic
tnaput
FSLx
put data to link x test-only
n = non-blocking
a = atomic
ncaput
rA, FSLx
put control to link x
n = non-blocking
a = atomic
tncaput
FSLx
put control to link x test-only
n = non-blocking
a = atomic
0 1 1 0 1 1 0 0 0 0 0 rA 1 n c t a 0 0 0 0 0 0 0 FSLx
0 6 11 16 28
31
Description
MicroBlaze will write the value from register rA to the link x interface. If the available number of links
set by C_FSL_LINKS is less than or equal to FSLx, link 0 is used.
The put instruction has 16 variants.
The blocking versions (when ‘n’ is ‘0’) will stall MicroBlaze until there is space available in the interface.
The non-blocking versions will not stall MicroBlaze and will set carry to ‘0’ if space was available and
to ‘1’ if no space was available.
All data put instructions (when ‘c’ is ‘0’) will set the control bit to the interface to ‘0’ and all control put
instructions (when ‘c’ is ‘1’) will set the control bit to ‘1’.
The test versions (when ‘t’ bit is ‘1’) will be handled as the normal case, except that the write signal to
the link is not asserted (thus no source register is required).
Atomic versions (when ‘a’ bit is ‘1’) are not interruptible. This means that a sequence of atomic
instructions can be grouped together without an interrupt breaking the program flow. However, note
that exceptions might still occur.
When MicroBlaze is configured to use an MMU (C_USE_MMU >= 1) and not explicitly allowed by
setting C_MMU_PRIVILEGED_INSTR to 1 these instructions are privileged. This means that if these
instructions are attempted in User Mode (MSR[UM] = 1) a Privileged Instruction exception occurs.
