Xilinx ZCU106 User Manual

ZCU106 Board User Guide 96
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
Table 3-38: GTH Transceiver Bank 224 Interface Connections
XCZU7EV
(U1) Pin
XCZU7EV Pin
Name
Schematic Net Name
(2)
Connected To
Pin No. Pin Name Device
AH4 MGTHTXP0 PCIE_TX3_P
(1)
A29 PERp3
PCIe 4-lane edge
connector P3
AH3 MGTHTXN0 PCIE_TX3_N
(1)
A30 PERn3
AJ2 MGTHTXP1 PCIE_RX3_P B27 PETp3
AJ1 MGTHTXN1 PCIE_RX3_N B28 PETn3
AG6 MGTHTXP2 PCIE_TX2_P
(1)
A25 PERp2
AG5 MGTHTXN2 PCIE_TX2_N
(1)
A26 PERn2
AG2 MGTHRXP0 PCIE_RX2_P B23 PETp2
AG1 MGTHRXN0 PCIE_RX2_N B24 PETn2
AE6 MGTHRXP1 PCIE_TX1_P
(1)
A21 PERp1
AE5 MGTHRXN1 PCIE_TX1_N
(1)
A22 PERn1
AF4 MGTHRXP2 PCIE_RX1_P B19 PETp1
AF3 MGTHRXN2 PCIE_RX1_N B20 PETn1
AD4 MGTHTXP3 PCIE_TX0_P
(1)
A16 PERp0
AD3 MGTHTXN3 PCIE_TX0_N
(1)
A17 PERn0
AE2 MGTHRXP3 PCIE_RX0_P B14 PETp0
AE1 MGTHRXN3 PCIE_RX0_N B15 PETn0
AB8 MGTREFCLK0P PCIE_CLK_P
(1)
A13 REFCLK+
AB7 MGTREFCLK0N PCIE_CLK_N
(1)
A14 REFCLK-
AA10 MGTREFCLK1P USER_SMA_MGT_CLOCK_C_P 1SIG SMA J79
AA9 MGTREFCLK1N USER_SMA_MGT_CLOCK_C_N 1SIG SMA J80
Notes:
1. Series capacitor coupled.
2. MGT connections I/O standard not applicable.
