ZCU106 Board User Guide 97
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
Table 3-39: GTH Transceiver Bank 225 Interface Connections
XCZU7EV
(U1) Pin
XCZU7EV Pin
Name
Schematic Net Name
(2)
Connected To
Pin
No.
Pin Name Device
AC6 MGTHTXP0 SDI_MGT_TX_P
(1)
3SDI_P
M23145G_14PG
re-clocker
AC5 MGTHTXN0 SDI_MGT_TX_N
(1)
4SDI_N
AC2 MGTHRXP0 SDI_MGT_RX_P
(1)
20 SDO0_P
M23554G_14PG
re-clocker
AC1 MGTHRXN0 SDI_MGT_RX_N
(1)
19 SDO0_N
AA6 MGTHTXP1 SMA_MGT_TX_P 1 SIG MGT SMA J72
AA5 MGTHTXN1 SMA_MGT_TX_N 1 SIG MGT SMA J42
AB4 MGTHRXP1 SMA_MGT_RX_C_P
(1)
1SIG MGT SMA J74
AB3 MGTHRXN1 SMA_MGT_RX_C_N
(1)
1SIG MGT SMA J73
Y4 MGTHTXP2 SFP0_TX_P 18 TD_P
SFP0 connector P1
Y3 MGTHTXN2 SFP0_TX_N 19 TD_N
AA2 MGTHRXP2 SFP0_RX_P 13 RD_P
AA1 MGTHRXN2 SFP0_RX_N 12 RD_N
W6 MGTHTXP3 SFP1_TX_P 18 TD_P
SFP0 connector P2
W5 MGTHTXN3 SFP1_TX_N 19 TD_N
W2 MGTHRXP3 SFP1_RX_P 13 RD_P
W1 MGTHRXN3 SFP1_RX_N 12 RD_N
Y8 MGTREFCLK0P FMC_HPC1_GBTCLK0_M2C_C_P
(1)
D4 GBTCLK0_M2C_P
FMC HPC1 J4
Y7 MGTREFCLK0N FMC_HPC1_GBTCLK0_M2C_C_N
(1)
D5 GBTCLK0_M2C_N
W10 MGTREFCLK1P SFP_SI5328_OUT_C_P
(1)
28 CKOUT1_P
SI5328B U20
W9 MGTREFCLK1N SFP_SI5328_OUT_C_N
(1)
29 CKOUT1_N
Notes:
1. Series capacitor coupled.
2. MGT connections I/O standard not applicable.
