Yamatake Corporation Operation of the Transmitter
ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter 5-59
5-11-3 :Analogue Bar Graph Display
An 11-segment analogue bar graph shows a total indication of the digital readout in %.
The relationship between the output value and the segment display status (on and
blinking) is as shown, below.
Output (OUT) Segment status
OUT<0% Blink
0% ≤ OUT < 5% On
5% ≤ OUT < 15%
15% ≤ OUT < 25%
25% ≤ OUT < 35%
35% ≤ OUT < 45%
45% ≤ OUT < 55%
55% ≤ OUT < 65%
65% ≤ OUT < 75%
75% ≤ OUT < 85%
85% ≤ OUT < 95%
95% ≤ OUT < 100%
100% < OUT Only the far most
segment blinks.
In the constant current mode, the entire bar graph blinks.
In this case, the bar graph and digital display blink alternately.
