Yamatake Corporation Operation of the Transmitter
ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter 5-5
5-2-4 :Checking Display Setting
Procedure
Check the display setting (flow rate/linear/display flow rate) of the transmitter, using
this procedure.
To change the setting, refer to "6-7-4 : Display or Change Indicator Display Format
(Flow Rate /Linear/ Display Flow Rate)".
Step Description SFC screen
1
Press the key.
2
Press the key.
3
Press the key.
Square root output
Linear output and linear display
Linear output and flow rate display
4
Press the key twice.
B
CONF
DSTJ CONFIG
CONFORM?
H
NEXT
DSTJ CONFIG
DISPLAY?
ENTER
( Yes )
NON-VOL
DISPLAY CONF
FLOW
DISPLAY CONF
LINEAR
DISPLAY CONF
DISP FLOW
CLR
( No )
DSTJ FIT-1234
READY...
To Next Page
