Installation Yamatake Corporation
4-24 ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter
Summary
For wiring the transmitter, you simply connect the positive (+) and negative (-) loop
wires to the positive (+) and negative (-) signal terminals on the terminal block in the
transmitters electronics housing as shown in Figure 4-19.
Figure 4-19 ST3000 Smart Transmitter Terminal Block.
METER SIGNELL
+ññ+ñ
Electronics
Housing
Terminal
Block
TEST
+
