Yamatake Corporation Operation Using SFC
ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter 6-11
6-3 : Before communicating using SFC
6-3-1 :What can be done using the SFC
It is possible to communicate with the transmitter, read data or change settings using
the SFC. This section explains the functions of the SFC organized by purpose.
CAUTION
Be sure to use the SFC with software version 7.0 or newer. Using the earlier versions
may cause incorrect operation.
6-3-1-1 Check during operation
The following functions are used while the transmitter is in operation.
• Starting communication: ID/DE READ key
• Displaying flow rate measured value: INPUT key
• Displaying transmitting output: OUTPUT key
• Displaying self-diagnostics result: STAT key
6-3-1-2 Data printing
The SFC with a printer has the following printing functions.
• Printing internal data: PRINT key
• Continuous printing of response results: ACT PRINT key
6-3-1-3 Setting and changing
The following functions are used to set or change the internal data of the transmitter.
• Tag number
• Output format
• Display format (flow rate/linear/display flow rate)
• Display format (engineering unit/% display)
• High and low limits of engineering quantity
• Low limit of set range
• High limit of set range
• Span of set range (Display only)
• Engineering unit of measured pressure
• Damping time constant
• Low flow cutoff value
• Burnout direction (Display only)
• Production number (Display only)
• Software version (Display only)
• Self-diagnostics result (Display only)
To Next Page
