2-5: Low Flow Cutoff Value / Dropout Point
This shows how to configure low flow cut value.
This function is effective only when Square Root is selected for the output format.
(Device setup) - (detailed setup) - (Signal condition) - (Cutoff mode)
When Square Root is selected for the output format, the following display will be
appeared.
DRP: Dropout Format (Linear / Zero)
MOD: Flow Rate Mode (Default / Expand)
When you select Dropout Format, you will be prompted to write cutoff mode and
press OK to return to “Cutoff mode” menu.
Configure dropout point selecting “Dropout Point”.
ST3000: TAG001
Cutoff mode
DRP: lin MOD: def
1 CUT-OFF: DEFAULT
2 DRP:lin MOD: def
3 DRP:lin MOD: def
4 DRP:zero MOD: def
HELP
SAVE HOME EXIT
ST3000: TAG001
Dropout Point
0.0%
0.0
HELP
DEL ESC ENTER
