Yamatake Corporation Appendix
ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter A-9
2-4: Indicator Display Format
This shows how to configure display format and/or its ranges.
(Device setup) - (Detailed setup) - (Device information) -(Meter type)
2-4-1: Display Type
2-4-2: EULO / EUHI
EULO and EUHI must be configured between -19999 and +19999 to indicate PV with
an engineering unit.
EULO: The value to be indicated when the output is 0%
EUHI: The value to be indicated when the output is 100%
Mode Description
E.UNIT (Linear) Displaying PV with engineering unit when output format is
linear.
% (Linear) Displaying PV with % when output format is linear.
E.UNIT (Dsp Flow) Displaying square rooted PV with engineering unit and out-
put is linear
% (Dsp Flow) Displaying square rooted PV with % and output is linear.
E.UNIT (Flow) Displaying square rooted PV with engineering unit and out-
put is also square rooted.
% (Flow) Displaying square rooted PV with % and output is also
square rooted.
ST3000: TAG001
Meter Type
1 Display type
2 EULO
3 EUHI
HELP
SAVE HOME EXIT
