Appendix Yamatake Corporation
A-12 ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter
2-8: Fill Fluid Temperature Compensation
Yamatake's unique fill fluid temperature compensation function for remote diaphragm
seals transmitter minimizes the effect of the fill fluid density changes by ambient tem-
perature on the transmitter performance.
This function implemented by inputting the height between the flanges on which the
transmitter is mounted.
(Device setup) - (Detailed setup) - (Signal condition) - (Height)
Key in the height between the flanges in meter.
When communicating with the transmitter without this function, the screen shows
“0.00 m”.
Keying in “0” disables the function.
2-9: Adjusting Damping Time
You can adjust the damping time to reduce the output noise.
(Device setup) - (Detailed setup) - (Signal condition) - (PV damping)
When PV damping menu, key in appropriate damping time from 0.0 to 128.0, and the
press ENTER. A display will prompt when you enter the value out of range that the
value is out of range.
ATTENTION
The damping time set by HART® Communicator might not be corresponding to that
which is displayed on the SFC. Reconfigure the damping time with SFC when the
transmitter is used in the DE enable mode. (ref. 5.2 DE Mode)
ST3000: TAG001
HEIGHT
0.00 m
HELP
PREV SAVE EXIT
ST3000: TAG001
PV damping
0.5 s
130
HELP
DEL ESC ENTER
Value out of range
To Next Page
