Installation Yamatake Corporation
4-2 ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter
4-2 : Mounting ST3000 Smart Transmitter
Summary
You can mount all transmitter models except those with integral flanges to a 2-inch
(50 mm) vertical or horizontal pipe using our optional angle or flat mounting bracket
or a bracket of your own. Those models with integral flanges are supported by the
flange connection.
Figure 4-1 shows typical bracket mounted and flange mounted transmitter installations
for comparison.
Figure 4-1 Typical Bracket Mounted and Flange Mounted Installations.
