Operation Using SFC Yamatake Corporation
6-52 ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter
6-9 : Writing a Memo
6-9-1 :Recording in Scratch Pad 1
This function enables recording of memos in the SFC’s scratch pad. Scratch pads 1
and 2 are available for notes from one technician to another, for specific instruments,
for example. Scratch pads are common to most data acquisition systems.
How to record memo in scratch pad 1:
Here, 99-4 ZERO CHECK (Zero point was checked in April 1999) is recorded.
Step Description SFC screen
1
Press the and keys, in that
order.
2
Press the , , , and
keys, in that order.
3
Press the and keys, in that
order.
4
Press the , , , ,
, , , , and
keys, in that order.
SHIFT
SCR PAD
SHIFT-
DSTJ FIT-1234
WORKING...
SCR PADS 1
XXXXXXXXXXXXXXXX
P
9
PRINT
T
6
TIME
O
8
FEED
SCR PADS 1
99-4 XXXXXXXXXXX
ALPHA
SCR PAD
SCR PADS 1
99-4 XXXXXXXXXXX
Z
0
ACT PR
LRV
E
0%
R
4
O
8
FEED
SCR PAD
C
DAMP
H
NEXT
LRV
E
0%
C
DAMP
COR-
K
RECT
RESET
SCR PADS 1
99-4 ZERO CHECK
