Yamatake Corporation Operation Using SFC
ST3000 Smart Transmitter Series 900 Electronic Differential Pressure/Pressure Transmitter 6-3
The following table describes the components of the SFC.
Name Description
Paper roll compartment - Stores heat-sensitive paper roll for print out.
Printer section (option) - This is an optional item.
- A 24 characters/line thermal printer.
- Prints out internal data of the transmitter or communi-
cation data.
- The printer section is one with the main unit and can-
not be separated.
Display window (screen) - Displays messages or data from the transmitter in 16
characters x 2 lines.
- The data display screen is available in either English
or Japanese.
Power switch - Turning ON the power switch of the SFC automati-
cally starts self-diagnostics.
Keyboard - There are 32 touch keys.
- Each key provides a separate and other functions are
accessed after pressing the SHIFT key.
- The keyboard is available in either English or Japa-
nese version.
Communication cable
connector
- Connect the plug side of the communication cable.
Communication cable - Be sure to use the supplied dedicated cables.
Battery charger connec-
tor
- Connect the plug side of the battery charger.
Battery charger - Charge the battery of the SFC using the supplied bat-
tery charger.
~Note When the battery voltage drops, the follow-
ing sign appears in the display window.
:
To Next Page
