HOA Keypad Display Error Name
The following simultaneous contradictory
settings:
• H3-02, H3-10, or H3-06 = B (PID Feedback)
while H6-01
(Pulse Train Input) = 1 (PID Feedback)
• H3-02, H3-10, or H3-06 = C (PID Target Value)
while H6-01 = 2
(pulse train input sets the PID target value)
Disable one of the PID selections.
HOA Keypad Display Error Name
oPE09
PID Control Selection Fault
PID control function selection is incorrect. Requires that PID control is enabled (b5-01 = 1 to 4).
Cause Possible Solutions
The following simultaneous contradictory settings
have occurred:
• b5-15 is not set to 0.0 (PID Sleep Function
Operation Level)
• The stopping method is set to either DC
Injection Braking or coast to stop with a timer
(b1-03 = 2 or 3).
• Set b5-15 to a value other than 0.0.
• Set the stopping method to coast to stop or ramp to stop (b1-03 = 0 or 1).
b5-01 is set to 1 or 2, enabling PID control, but the
lower limit for the frequency reference (d2-02) is
not set to 0 while reverse output is enabled (b5-11
= 1).
Correct the parameter settings.
b5-01 is set to 3 or 4, enabling PID control, but the
lower limit for the frequency reference (d2-01) is
not 0.
Correct the parameter settings.
HOA Keypad Display Error Name
oPE10
V/f Data Setting Error
One of the following setting errors has occurred:
E1-09 ≤ E1-07 < E1-06 ≤ E1-11 ≤ E1-04
Cause Possible Solutions
V/f pattern setting error. Correct the settings for E1-04, E1-06, E1-07, E1-09, and E1-11.
HOA Keypad Display Error Name
oPE11
Carrier Frequency Setting Error
Correct the setting for the carrier frequency.
Cause Possible Solutions
The following simultaneous contradictory settings
have occurred: C6-05 > 6 and C6-04 > C6-03
(carrier frequency lower limit is greater than the
upper limit).
If C6-05 ≤ 6, the drive operates at C6-03.
Correct the parameter settings.
The upper and lower limits between C6-02 and
C6-05 are contradictory.
5.4 Operator Programming Errors
YASKAWA TOEP YAIP1W 01F YASKAWA AC Drive - iQpump1000 User Manual
287
5
Troubleshooting
