No.
(Addr.
Hex)
Name LCD Display Description
Analog
Output Level
Unit
U1-11
(004A)
<7>
Output Terminal
Status
Output Term Sts
Displays the output terminal status.
U1 - 11=
00000000
Multi-Function
Digital Output
(terminal MD-ME-MF)
Digital Output
(terminal M1-M2)
Digital Output
Multi-Function
Multi-Function
Not Used
Fault Relay
(terminal MA-MC closed
MA-MC open)
1
1
1
1
0
(terminal M3-M4)
No signal output
available
–
U1-12
(004B)
Drive Status Int Ctl Sts 1
Verifies the drive operation status.
U1 - 12=
00000000
During run
During zero-speed
During REV
During fault reset
signal input
During speed agree
Drive ready
During alarm
detection
During fault detection
1
1
1
1
1
1
1
1
No signal output
available
–
U1-13
(004E)
<7>
Terminal A1 Input
Level
Term A1 Level
Displays the signal level to analog input terminal A1.
10 V: 100% 0.1%
U1-14
(004F)
<7>
Terminal A2 Input
Level
Term A2 Level
Displays the signal level to analog input terminal A2.
10 V: 100% 0.1%
U1-15
(0050)
<7>
Terminal A3 Input
Level
Term A3 Level
Displays the signal level to analog input terminal A3.
10 V: 100% 0.1%
U1-16
(0053)
Output Frequency after
Soft Starter
SFS Output
Displays output frequency with ramp time and S-curves. Units
determined by o1-03.
10 V: Max
frequency
0.01 Hz
U1-18
(0061)
oPE Fault Parameter OPE Error Code
Displays the parameter number that caused the oPE02 operation
error.
No signal output
available
–
U1-19
(0066)
MEMOBUS/Modbus
Error Code
Transmit Err
Displays the contents of a MEMOBUS/Modbus error.
U1 - 19=
00000000
CRC Error
Data Length Error
Not Used
Parity Error
Overrun Error
Framing Error
Timed Out
Not Used
1
1
0
1
1
1
1
0
No signal output
available
–
U1-24
(007D)
Input Pulse Monitor Term RP Inp Freq
Displays the frequency to pulse train input terminal RP. Determined by
H6-02
1 Hz
U1-25
(004D)
<7>
Software Number
(Flash)
CPU 1 SW Number
FLASH ID
No signal output
available
–
U1-26
(005B)
Software No. (ROM) CPU 2 SW Number
ROM ID No signal output
available
–
B.16 U: Monitors
