IP20/NEMA 1, UL Type 1 Kit Selection
Customers may convert IP00/Open Type models to IP20/NEMA 1, UL Type 1 enclosures. Refer to Table 2.11 to select the
appropriate IP20/NEMA 1, UL Type 1 Kit when performing the conversion.
Contact a Yaskawa representative for IP20/NEMA 1, UL Type 1 Kit availability for IP00/Open Type models not listed.
Table 2.11 IP20/NEMA 1, UL Type 1 Kit Selection
IP00/Open Type
Drive Model
IP20/NEMA 1, UL Type 1 Kit Code Comments
2A0250A
100-054-503
Refer to IP20/NEMA 1, UL Type 1 Enclosure
Drives on page 44 for drive dimensions with the
IP20/NEMA 1, UL Type 1 Kit installed.
2A0312A
2A0360A
4A0208A
4A0250A
100-054-5044A0296A
4A0362A
5A0125A
100-054-503
5A0145A
5A0192A
100-054-504
5A0242A
2.1 Mechanical Installation
