YASKAWA MP Series User Manual

10.3 Main Commands and Subcommands
10.3.4 Subcommand Details
10-23
Settings for Connecting Inverters
 Monitoring Parameters
Name Register No.
Setting
Range
Remarks
Subcommand Response Code
IW0A 0 to 9 01: Inverter I/O Control
Subcommand Status
IW0B Bit
Bit 0 (Command execution flag)
ON from the first
execution until exe-
cution is completed.
Stays OFF after the
first execution is
completed.
Bit 3 (Command error completed
status)
ON when an error
occurs during the
command process-
ing.
Bit 8 (Command execution com-
pleted)
Always ON after
execution is com-
pleted.
Auxiliary Input Data Option Selec-
tion Monitor
IW0F Bit Displays the optional data that have been entered.
Motor Speed (Option)
IW13
Valid when bit 0 of Auxiliary Input Data Option Selec-
tion (OW0F) is ON.
Torque Reference (U1-09) (Op-
tion)
IW14
Valid when bit 1 of Auxiliary Input Data Option Selec-
tion (OW0F) is ON.
Encoder Counter (Option)
IW15 0 to 65535
Valid when bit 2 of Auxiliary Input Data Option Selec-
tion (OW0F) is ON.
Frequency Reference (U1-01)
(Option)
IW16
Valid when bit 3 of Auxiliary Input Data Option Selec-
tion (OW0F) is ON.
Multi-function Analog Input A2
(Option)
IW17
Valid when bit 4 of Auxiliary Input Data Option Selec-
tion (OW0F) is ON.
Main Bus Voltage (Option)
IW18
Valid when bit 5 of Auxiliary Input Data Option Selec-
tion (OW0F) is ON.
Alarm Code (Option)
IW19
Valid when bit 6 of Auxiliary Input Data Option Selec-
tion (OW0F) is ON.
Alarm Code (Option)
IW1A
Valid when bit 7 of Auxiliary Input Data Option Selec-
tion (OW0F) is ON.
Multi-function Analog Input A3
(Option)
IW1C
V
alid when bit 9 of Auxiliary Input Data
Option Selec-
tion (OW0F) is ON.
Digital Input Terminal (Option)
IW1D
Valid when bit A of Auxiliary Input Data Option Selec-
tion (OW0F) is ON.
Multi-function Analog Input A1
(Option)
IW1E
Valid when bit B of Auxiliary Input Data Option Selec-
tion (OW0F) is ON.
Encoder Counter (CH2) (Option)
IW1F
Valid when bit C of Auxiliary Input Data Option Selec-
tion (OW0F) is ON.
Subcommand Response Status
IW31 Bit
Refer to Subcommand Response Status of 10.4.3 Moni-
toring Parameter List.
