YASKAWA MP Series User Manual

10.3 Main Commands and Subcommands
10.3.4 Subcommand Details
10-24
( 3 ) Read User Constant
 Description
Reads the specified inverter user constant from the Inverter.
 Valid only in MECHATROLINK-II 32-byte mode.
 Setting Parameters
 Monitoring Parameters
Name Register No. Setting Range Remarks
Subcommand Code
OW0A 0 to 9 02: Read User Constant
Auxiliary Inverter Constant Number
OW42 0 to FFFFH
Auxiliary Inverter Constant Number
Size
OW43 1 to 4
Data type: Word (Enter the size of user con-
stant that read out from the leading user con-
stant number of the auxiliary inverter.)
Name Register No.
Setting
Range
Remarks
Subcommand Response Code
IW0A 0 to 9 02: Read User Constant
Subcommand Status
IW0B Bit
Bit 0 (Command execution flag)
ON during execu-
tion
Bit 3 (Command error completed
status)
ON when an error
occurs during com-
mand processing.
Bit 8 (Command execution com-
pleted)
ON when command
execution is com-
pleted.
Subcommand Response Status
IW31 Bit
Refer to Subcommand Response Status of 10.4.3 Moni-
toring Parameter List.
Auxiliary Inverter User Constant
Number
IW42 0 to FFFFH
Auxiliary User Constant
Reading Data 1
IW44 0 to 65535
Auxiliary User Constant
Reading Data 2
IW45 0 to 65535
Auxiliary User Constant
Reading Data 3
IW46 0 to 65535
Auxiliary User Constant
Reading Data 4
IW47 0 to 65535
