Pn408
2
Torque Related
Function Switch
0000 to 1111 − 0000 −−−
Pn409 2 1st Notch Filter Frequency 50 to 5000 1 Hz 5000 Immediately Tuning
5.9.3
Pn40A 2 1st Notch Filter Q Value 50 to 1000 0.01 70 Immediately Tuning
Pn40B 2 1st Notch Filter Depth 0 to 1000 0.001 0 Immediately Tuning
Pn40C 2 2nd Notch Filter Frequency 50 to 5000 1 Hz 5000 Immediately Tuning
Pn40D 2 2nd Notch Filter Q Value 50 to 1000 0.01 70 Immediately Tuning
Pn40E 2 2nd Notch Filter Depth 0 to 1000 0.001 0 Immediately Tuning
Pn40F 2
2nd Step 2nd Torque
Reference Filter Frequency
100 to 5000 1 Hz 5000 Immediately Tuning
Pn410 2
2nd Step 2nd Torque
Reference Filter Q Value
50 to 100 0.01 50 Immediately Tuning
Pn412 2
1st Step 2nd Torque
Reference Filter Time
Constant
0 to 65535 0.01 ms 100 Immediately Tuning 5.8.1
Pn415 2 Reserved (Do not change.) −−0 −−−
Pn423 2 Reserved (Do not change.) −−0000 −−−
Pn424 2
Torque Limit at Main Circuit
Voltage Drop
0 to 100
1%
*2
50 Immediately Setup
4.3.7
Pn425 2
Release Time for Torque Limit
at Main Circuit Voltage Drop
0 to 1000 1 ms 100 Immediately Setup
Pn456 2
Sweep Torque Reference
Amplitude
1 to 800 1% 15 Immediately Tuning 6.21
∗2. Percentage (%) of rated motor torque.
(cont’d)
Parameter
No.
Size Name
Setting
Range
Units
Factory
Setting
When
Enabled
Classification
Reference
Section
1st Step Notch Filter Selection
When
Enabled
Classification
Reference
Section
0 N/A
Immediately Setup
5.9.3
1 Uses 1st step notch filter for torque reference.
Speed Limit Selection
When
Enabled
Classification
Reference
Section
0 Uses the smaller of the maximum motor speed and
the value of Pn407 as the speed limit value.
After restart Setup
4.8.8
1 Uses the smaller of the overspeed detection speed
and the value of Pn407 as the speed limit value.
2nd Step Notch Filter Selection
When
Enabled
Classification
Reference
Section
0 N/A
Immediately Setup
5.9.3
1 Uses 2nd step notch filter for torque reference.
Friction Compensation Function Selection
When
Enabled
Classification
Reference
Section
0 Disables friction compensation function.
Immediately Setup
5.8.2
1 Enables friction compensation function.
4th 3rd 2nd 1st
digit digit digit digit
n.

