10 Appendix
10-36
Pn506 0
Brake Reference
-
Servo OFF Delay
Time
Immediately
Pn507 100 Brake Reference Output Speed Level Immediately
Pn508 50
Waiting Time for Brake Signal When
Motor Running
Immediately
Pn509 20 Instantaneous Power Cut Hold Time Immediately
Pn50A 1881 Input Signal Selection 1 After restart
Pn50B 8882 Input Signal Selection 2 After restart
Pn50E 0000 Output Signal Selection 1 After restart
Pn50F 0100 Output Signal Selection 2 After restart
Pn510 0000 Output Signal Selection 3 After restart
Pn511 6543 Input Signal Selection 5 After restart
Pn512 0000 Output Signal Inverse Setting After restart
Pn517 0000 Reserved –
Pn51B 1000
Excessive Error Level Between Ser-
vomotor and Load Positions
Immediately
Pn51E 100
Excessive Position Error Warning
Level
Immediately
Pn520 5242880
Excessive Position Error Alarm
Level
Immediately
Pn522 7 Positioning Completed Width Immediately
Pn524 1073741824 NEAR Signal Width Immediately
Pn526 5242880
Excessive Position Error Alarm
Level at Servo ON
Immediately
Pn528 100
Excessive Position Error Warning
Level at Servo ON
Immediately
Pn529 10000 Speed Limit Level at Servo ON Immediately
Pn52A 20
Multiplier per One Fully-closed
Rotation
Immediately
Pn52B 20 Overload Warning Level Immediately
Pn52C 100
Derating of Base Current at Detecting
Overload of Motor
After restart
Pn52D 50 Reserved –
Pn52F 0FFF Reserved –
Pn530 0000
Program JOG Operation Related
Switch
Immediately
Pn531 32768 Program JOG Movement Distance Immediately
Pn533 500 Program JOG Movement Speed Immediately
Pn534 100
Program JOG Acceleration/Decelera-
tion Time
Immediately
Pn535 100 Program JOG Waiting Time Immediately
Pn536 1
Number of Times of Program JOG
Movement
Immediately
Pn550 0 Analog Monitor 1 Offset Voltage Immediately
Pn551 0 Analog Monitor 2 Offset Voltage Immediately
Pn552 100 Analog Monitor Magnification (×1) Immediately
Pn553 100 Analog Monitor Magnification (×2) Immediately
Pn560 400 Remained Vibration Detection Width Immediately
Pn561 100 Overshoot Detection Level Immediately
(cont’d)
Parameter
Factory
Setting
Name
When
Enabled
