10.2 Parameter Recording Table
10-37
Pn600 0 Regenerative Resistor Capacity Immediately
Pn601 0Reserved–
Pn800 0040 Communications Control Immediately
Pn801 0003
Application Function Select 6
(Software LS)
Immediately
Pn803 10 Origin Range Immediately
Pn804 1073741823 Forward Software Limit Immediately
Pn806 -1073741823 Reverse Software Limit Immediately
Pn808 0 Absolute Encoder Origin Offset
Immediately
∗2
Pn80A 100 1st Linear Acceleration Constant
Immediately
∗3
Pn80B 100 2nd Linear Acceleration Constant
Immediately
∗3
Pn80C 0
Acceleration Constant Switching
Speed
Immediately
∗3
Pn80D 100 1st Linear Deceleration Constant
Immediately
∗3
Pn80E 100 2nd Linear Deceleration Constant
Immediately
∗3
Pn80F 0
Deceleration Constant Switching
Speed
Immediately
∗3
Pn810 0
Exponential Function Acceleration/
Deceleration Bias
Immediately
∗3
Pn811 0
Exponential Function Acceleration/
Deceleration Time Constant
Immediately
∗3
Pn812 0 Movement Average Time
Immediately
∗3
Pn814 100
Final Travel Distance for External
Positioning
Immediately
∗3
Pn816 0000 Homing Mode Setting
Immediately
∗3
Pn817 50 Homing Approach Speed 1
Immediately
∗3
Pn818 5 Homing Approach Speed 2
Immediately
∗3
Pn819 100 Final Travel Distance for Homing
Immediately
∗3
Pn81E 0000 Input Signal Monitor Selection Immediately
Pn81F 0000 Command Data Allocation After restart
Pn820 0 Forward Latching Allowable Area Immediately
Pn822 0 Reverse Latching Allowable Area Immediately
Pn824 0000 Option Monitor 1 Selection Immediately
Pn825 0000 Option Monitor 2 Selection Immediately
Pn827 100
Linear Deceleration Constant 1 for
Stopping
Immediately
∗3
Pn829 0
SVOFF Waiting Time (SVOFF at
deceleration to stop)
Immediately
∗2. Enabled after the SENS_ON is entered.
∗3. Change the setting when the reference is stopped (DEN is set to 1), because the change will affect the output during
operation.
(cont’d)
Parameter
Factory
Setting
Name
When
Enabled
To Next Page
