Factory Settings that Change with the Inverter Capacity (o2-04)
200 V Class Inverters
Parameter
Number
Name Unit
Factory Setting
- Inverter Capacity kW 3.7 5.5 7.5 11 15 18.5 22
o2-04 kVA selection - 4 5 6 7 8 9 A
E2-01
(E4-01)
Motor rated current A 14.00 19.60 26.60 39.7 53.0 65.8 77.2
E2-02
(E4-02)
Motor rated slip Hz 2.73 1.50 1.30 1.70 1.60 1.67 1.70
E2-03
(E4-03)
Motor no-load current A 4.50 5.10 8.00 11.2 15.2 15.7 18.5
E2-05
(E4-05)
Motor line-to-line resistance W 0.771 0.399 0.288 0.230 0.138 0.101 0.079
E2-06
(E4-06)
Motor leak inductance % 19.6 18.2 15.5 19.5 17.2 20.1 19.5
E2-10
Motor iron loss for torque
compensation
W 112 172 262 245 272 505 538
L8-02 Overheat pre-alarm level °C75757580657575
