Component Names
Inverters of 18.5 kW or Less
The external appearance and component names of the Inverter are shown in Fig 1.4. The Inverter with the ter-
minal cover removed is shown in Fig 1.5.
Fig 1.4 Inverter Appearance (18.5 kW or Less)
Fig 1.5 Terminal Arrangement (18.5 kW or Less)
Front cover
Digital Operator
Terminal cover
Bottom protective cover
Nameplate
Diecast cover
Mounting
Control circuit terminals
Main circuit terminals
Ground terminal
Charge indicator
