8-2
Standard Inverter Specifications
The standard Inverter specifications are listed by capacity in the following tables.
Specifications by Model
Specifications are given by model in the following tables.
200V Class
* 1. The maximum applicable motor output is given for a standard 4-pole Yaskawa motor. When selecting the actual motor and Inverter, be sure that the Inverter's
rated current is applicable for the motor's rated current.
* 2. A transformer with dual star-delta secondary is required on the power supply for 12-pulse rectification.
Table 8.1 200 V Class Inverters
Model Number CIMR-L7C 23P7 25P5 27P5 2011 2015 2018 2022 2030 2037 2045 2055
Max. applicable motor output
(kW)
*1
3.7 5.5 7.5 11 15 18.5 22 30 37 45 55
Rated output capacity
(kVA)
7 10142027334054677693
Rated output current (A) 17.5 25 33 49 64 80 96 130 160 183 224
Max. output voltage (V)
3-phase; 200, 208, 220, 230, or 240 VAC
(Proportional to input voltage.)
Max. output frequency
(Hz)
Up to 120Hz available by programing.
Rated voltage (V)
Rated frequency (Hz)
3-phase, 200/208/220/230/240 VAC, 50/60 Hz
Rated input current (A) 21 25 40 52 68 96 115 156 176 220 269
Allowable voltage fluctua-
tion
+ 10%, - 15%
Allowable frequency fluc-
tuation
±5%
Measures
for power
supply
harmonics
DC reactor Optional
12-pulse rec-
tification
Not possible
O
utput rat
i
ngsPower supp
l
y c
h
aracter
i
st
i
cs
C
ontro
l
c
h
aracter
i
st
i
cs
