Inverter Model Numbers
The model number of the Inverter on the nameplate indicates the specification, voltage class, and maximum
motor capacity of the Inverter in alphanumeric codes.
Fig 1.2 Inverter Model Numbers
Inverter Specifications
The Inverter specifications (“SPEC”) on the nameplate indicate the voltage class, maximum motor capacity,
the protective structure, and the revision of the Inverter in alphanumeric codes.
Fig 1.3 Inverter Specifications
CIMR  L7 A 2 3P7
Inverter
Varispeed L7
No.
A
Specification
with IM drives (open loop Vector Control)
No.
Voltage Class
2
4
AC Input, 3-phase, 200 V
AC Input, 3-phase, 400 V
No.
Max. Motor Capacity
3P7
3.7 kW
5P5
5.5 kW
to
to
55
55 kW
P Indicates the decimal point.
B
with IM drives (PG card are optional)
C
with convertible drives for IM and PM
(with built-in PG interface)
2 3P7 1
No.
2
4
Voltage Class
AC Input, 3-phase, 200 V
AC Input, 3-phase 400 V
No.
Max. Motor Capacity
3P7
3.7 kW
5P5
5.5 kW
to
to
55
55 kW
No.
Protective Structure
0
Open chassis (IEC IP00)
1
Enclosed wall-mounted
(NEMA Type 1)
“P” Indicates the decimal point
7
(IEC IP20)
Enclosed wall-mounted
