YASKAWA Varispeed L7 User Manual

4-18
 Reference Parameters: d
Preset Reference: d1
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Display
d1-01
Frequency
reference 1
Sets the frequency reference.
0 to
120.00
*1*2
0.00 Hz Yes A A A 280H 5-7
Reference 1
d1-02
Frequency
reference 2
Sets the frequency reference
when multi-step speed com-
mand 1 is ON for a multi-func-
tion input.
0.00 Hz Yes A A A 281H 5-7
Reference 2
d1-03
Frequency
reference 3
Sets the frequency reference
when multi-step speed com-
mand 2 is ON for a multi-func-
tion input.
0.00 Hz Yes A A A 282H 5-7
Reference 3
d1-04
Frequency
reference 4
Sets the frequency reference
when multi-step speed com-
mands 1 and 2 are ON for
multi-function inputs.
0.00 Hz Yes A A A 283H 5-7
Reference 4
d1-05
Frequency
reference 5
Sets the frequency when multi-
step speed command 3 is ON
for a multi-function input.
0.00 Hz Yes A A A 284H 5-7
Reference 5
d1-06
Frequency
reference 6
Sets the frequency reference
when multi-step speed com-
mands 1 and 3 are ON for
multi-function inputs.
0.00 Hz Yes A A A 285H 5-7
Reference 6
d1-07
Frequency
reference 7
Sets the frequency reference
when multi-step speed com-
mands 2 and 3 are ON for
multi-function inputs.
0.00 Hz Yes A A A 286H 5-7
Reference 7
d1-08
Frequency
reference 8
Sets the frequency reference
when multi-step speed com-
mands 1, 2, and 3 are ON for
multi-function inputs.
0.00 Hz Yes A A A 287H 5-7
Reference 8
d1-09
Vn reference Sets the frequency reference
when multi-step speed com-
mand 4 is ON for a multi-func-
tion input.
50.00
Hz
Yes Q Q Q 288H 5-7
Vn reference
d1-10
V1 reference Sets the frequency reference
when multi-step speed com-
mands 1 and 4 are ON for
multi-function inputs.
0.00 Hz Yes A A A 28BH 5-7
V1 reference
d1-11
V2 reference Sets the frequency reference
when multi-step speed com-
mands 2 and 4 are ON for a
multi-function inputs.
0.00 Hz Yes A A A 28CH 5-7
V2 reference
