YASKAWA Varispeed L7 User Manual

User Parameter Tables
4-45
4
 Copy Function: o3
 Lift Function Parameters: S
S1 Brake Sequence
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Display
o3-01
Copy func-
tion selection
0: Normal operation
1: READ (Inverter to
Operator)
2: COPY (Operator to
Inverter)
3: Verify (compare)
0 to 3 0 No A A A 515H 5-56
Copy Func-
tion Sel
o3-02
Read permis-
sion selection
0: READ prohibited
1: READ permitted
0 or 1 0 No A A A 516H 5-56
Copy
Allowable
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Display
S1-02
DC injection
braking cur-
rent at start
Sets the DC injection braking
current as a percentage of the
Inverter rated current.
0 to
100
50% No A A No 681H -
DC Inj I
@start
S1-03
DC injection
braking curr-
net at stop
Sets the DC injection braking
current as a percentage of the
Inverter rated current.
0 to
100
50% No A A No 682H -
DC Inj I
@stop
S1-04
DC injection
braking time
at start
Used to set the time to perform
DC injection braking at start in
units of 1 second.
Used to stop coasting motor
and restart it. When the set
value is 0, DC injection brak-
ing at start is not performed.
0.00
to
10.00
0.50 s
*
No A A A 18BH -
S1-05
DC injection
braking time
at stop
Used to set the time to perform
DC injection braking at stop in
units of 1 second.
Used to prevent coasting after
the stop command is input.
When the set value is 0.00, DC
injection braking at stop is not
performed.
0.00
to
10.00
0.60 s No A A A 18CH -
S1-06
Brake release
delay time
Used to set the time to output
Brake release command in
units of 1second.
0.00
to
10.00
0.20 No A A A 685H -
Brake open
delay
S1-07
Brake close
delay time
Used to set the time to output
Brake close command in units
of 1second.
0.00
to
S1-05
0.10 No A A A 685H -
Brake
CloseDelay
