Exterior and Mounting Dimensions
 Open Chassis Inverters (IP00)
Exterior diagrams of the Open Chassis Inverters are shown below.
Fig 1.8 Exterior Diagrams of Open Chassis Inverters
 Enclosed Wall-mounted Inverters (NEMA1xIEC IP20)
Exterior diagrams of the Enclosed Wall-mounted Inverters (NEMA1 y IEC IP20) are shown below.
Fig 1.9 Exterior Diagrams of Enclosed Wall-mounted Inverters
200 V Class Inverters of 22 or 55 kW
400 V Class Inverters of 22 to 55 kW
200 V/400 V Class Inverters of 3.7 to 18.5 kW
200 V Class Inverters of 22 or 55 kW
400 V Class Inverters of 22 to 55 kW
200 V/400 V Class Inverters of 3.7 to 18.5 kW
Grommet
