1-2
Varispeed L7 Introduction
Varispeed L7 Models
The Varispeed L7 Series includes Inverters in two voltage classes: 200 V and 400 V. The maximum motor capacities
vary from 3.7 to 55 kW (23 models).
Table 1.1 Varispeed L7 Models
* 200V/400V class 30KW-55KW model is developing.
Voltage
Class
Maximum
Motor
Capacity kW
Var i s p e ed L 7
Specifications
(Always specify through the protective structure when ordering.)
Output
Capacity
kVA
Basic Model
Number
Open Chassis (IEC IP00)
CIMR-L7C
Enclosed Wall-mounted
(NEMA 1) CIMR-L7C
200 V class
3.7 7 CIMR-L7C23P7
Remove the top and
bottom covers from the Enclosed
Wall-mounted model.
23P71
5.5 10 CIMR-L7C25P5 25P51
7.5 14 CIMR-L7C27P5 27P51
11 20 CIMR-L7C2011 20111
15 27 CIMR-L7C2015 20151
18.5 33 CIMR-L7C2018 20181
22 40 CIMR-L7C2022 20220 20221
30 54 CIMR-L7C2030 20300 20301
37 67 CIMR-L7C2037 20370 20371
45 76 CIMR-L7C2045 20450 20451
55 93 CIMR-L7C2055 20550 20551
400 V class
3.7 7 CIMR-L7C43P7
Remove the top and bottom cov-
ers from the Enclosed Wall-
mount model.
43P71
4.0 9 CIMR-L7C44P0 44P01
5.5 12 CIMR-L7C45P5 45P51
7.5 15 CIMR-L7C47P5 47P51
11 22 CIMR-L7C4011 40111
15 28 CIMR-L7C4015 40151
18.5 34 CIMR-L7C4018 40181
22 40 CIMR-L7C4022 40220 40221
30 54 CIMR-L7C4030 40300 40301
37 67 CIMR-L7C4037 40370 40371
45 80 CIMR-L7C4045 40450 40451
55 106 CIMR-L7C4055 40550 40551
