Digital Operation Display Functions and Levels
The following figure shows the Digital Operator/Monitor display hierarchy for the Inverter.
MENU
Drive Mode
Inverter can be operated and
its status can be displayed.
Quick Programming Mode
Minimum parameters required
for operation can be monitored
or set.
Advanced Programming Mode
All parameters can be moni-
tored or set.
Verify Mode
Parameters changed from the
default settings can be moni-
tored or set.
Autotuning Mode
Automatically sets motor
parameters for open-loop vec-
tor control or measures the
line-to-line resistance for V/f
control.
No. Function Page
U1 Status Monitor Parameters
4-50
U2 Fault Trace
4-55
U3 Fault History
4-57
A1 Initialize Mode
4-8
A2 User-specified Setting Mode
4-9
b1 Operation Mode Selections
4-10
b2 DC Injection Braking
4-10
b6 Dwell Functions
4-11
C1 Acceleration/Deceleration
4-12
C2 S-curve Acceleration/Deceleration
4-13
C3 Motor Slip Compensation
4-14
C4 Torque Compensation
4-15
C5 Speed Control (ASR)
4-16
C6 Carrier Frequency
4-17
d1 Preset Reference
4-18
d6 Field Weakening
4-19
E1 V/f Pattern
4-20
E2 Motor Setup
4-21
F1 PG Option Setup
4-23
F4 Analog Momitor Card
4-25
F5 Digital Output Card
4-26
F6 Serial Communications Settings
4-27
H1 Multi-function Digital Inputs
4-28
H2 Multi-function Digital Outputs
4-29
H3 Multi-function Analog Inputs
4-31
H5 MEMOBUS Communications
L1 Motor Overload
4-34
L2 Power Loss Ridethrough
4-34
L3 Stall Prevention
4-35
L4 Reference Detection
4-36
L5 Feed Restart
4-36
L6 Torque Detection
4-37
L7 Torque Limits
4-38
L8 Hardware Protection
4-39
N2 Automatic Frequency Regulator
4-40
N5 Feed Forward
o1 Monitor Selection
4-41
o2 Digital Operator/Monitor Functions
4-42
o3 Copy Function
4-45
S1 Brake Sequence
4-45
S2 Slip Compensation for lift
4-48
S3 Lift Specific Function
4-48
T
Motor Autotuning 4-49
