Confirmations upon Delivery
Checks
Check the following items as soon as the Inverter is delivered.
If you find any irregularities in the above items, contact the agency from which you purchased the Inverter or
your Yaskawa representative immediately.
Nameplate Information
There is a nameplate attached to the side of each Inverter. The nameplate shows the model number, specifica-
tions, lot number, serial number, and other information on the Inverter.
Example Nameplate
The following nameplate is an example for a standard Inverter: 3-phase, 400 VAC,
3.7 kW, IEC IP20 NEMA1(Type1) standards
Fig 1.1 Nameplate
Table 1.2 Checks
Item Method
Has the correct model of Inverter been
delivered?
Check the model number on the nameplate on the side of the Inverter.
Is the Inverter damaged in any way?
Inspect the entire exterior of the Inverter to see if there are any scratches or
other damage resulting from shipping.
Are any screws or other components
loose?
Use a screwdriver or other tools to check for tightness.
Inverter model
Inverter
specifications
Mass
Input specification
Output specification
Serial number
UL file number
Lot number
MADE IN JAPAN
YASKAWA ELECTRIC CORPORARION
SPEC: 43P71A
PRG:
M
s
MASS: 4.0 kg
CIMR-L7C43P7
AC3PH 380-480V 50/60Hz 10.2A
AC3PH 0-480V 0-120Hz 8.5A 3min. 50%ED 8.5kVA
FILE NO E131457
INPUT
OUTPUT
O/N
S/N
MODEL
