YASKAWA Varispeed L7 User Manual

4-28
 Terminal Function Parameters: H
Multi-function Digital Inputs: H1
Multi-function Digital Input Functions
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Display
H1-01
Terminal S3
function
selection
Multi-function input 1 0 to 88 24 No A A A 400H -
Terminal S3
Sel
H1-02
Terminal S4
function
selection
Multi-function input 2 0 to 88 14 No A A A 401H -
Terminal S4
Sel
H1-03
Terminal S5
function
selection
Multi-function input 3 0 to 88 3 No A A A 402H -
Terminal S5
Sel
H1-04
Terminal S6
function
selection
Multi-function input 4 0 to 88 4 No A A A 403H -
Terminal S6
Sel
H1-05
Terminal S7
function
selection
Multi-function input 5 0 to 88 6 No A A A 404H -
Terminal S7
Sel
Setting
Value
Function
Control Methods
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
3
Multi-step speed reference 1
If H3-09 is set to 2, this function is combined with the master/auxiliary speed switch.
Yes Yes Ye s -
4 Multi-step speed reference 2 Yes Yes Yes -
5 Multi-step speed reference 3 Yes Yes Yes -
6 Jog frequency command (higher priority than multi-step speed reference) Yes Yes Yes -
7 Accel/decel time 1 Yes Yes Yes 5-18
8 External baseblock NO (NO contact: Baseblock at ON) Yes Yes Yes 5-42
9 External baseblock NC (NC contact: Baseblock at OFF) Yes Yes Yes 5-42
F Not used (Set when a terminal is not used) - - -
14 Fault reset (Reset when turned ON) Yes Yes Yes 6-2
15
Emergency stop. (NO: Deceleration to stop in deceleration time set in C1-09 when
ON.)
Yes Yes Ye s 5-10
17
Emergency stop (NC: Deceleration to stop in deceleration time set in C1-09 when
OFF)
Yes Yes Ye s 5-10
18
Timer function input (Functions are set in b4-01 and b4-02 and the timer function
outputs are set in H1- and H2-.)
Yes Yes Ye s -
