YASKAWA Varispeed L7 User Manual

User Parameter Tables
4-29
4
 Multi-function Contact Outputs: H2
Multi-function Contact Output Functions
20 to 2F
External fault
Input mode: NO contact/NC contact, Detection mode: Normal/during operation
Yes Yes Ye s -
80 Nominal Speed Reference Yes Yes Yes -
81 Intermediate Speed Reference Yes No No -
82 Releveling Speed Reference Yes Yes Yes -
83 Leveling Speed Reference Yes Yes Yes -
84 Inspection Run Command Yes Yes Yes -
85 Battery Operation Command Yes Yes Yes -
86 Output Contactor Answer Back Signal Yes Yes Yes -
87 High Speed Limit Switch (UP) Yes Yes Yes -
88 High Speed Limit Switch (Down) Yes Yes Yes -
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Display
H2-01
Terminal
M1-M2 func-
tion selection
Multi-function contact
output 1
0 to 43 40 No A A A 40BH -
Term
M1-M2 Sel
H2-02
Terminal
M3-M4 func-
tion selection
Multi-function contact
output 2
0 to 43 41 No A A A 40CH -
Term
M3-M4 Sel
H2-03
Terminal
M5-M6 func-
tion selection
Multi-function contact
output 3
0 to 43 6 No A A A 40DH -
Term
M5-M6 Sel
Set-
ting
Value
Function
Control Methods
Page
V/f
Open
loop
Vector
Closed
Loop
Vector
0 During run (ON: run command is ON or voltage is being output) Yes Yes Yes 5-47
1 Zero-speed Yes Yes Yes 5-47
2
f
ref
/f
out
agree 1 (detection width L4-02 is used.)
Ye s Yes Ye s 5-24
3
f
ref
/f
set
agree 1 (ON: Output frequency = ±L4-01, with detection width L4-02 used
and during frequency agree)
Ye s Yes Ye s 5-24
4
Frequency detection 1 (ON: +L4-01 ≥ output frequency ≥ -L4-01, with detection
width L4-02 used)
Ye s Yes Ye s 5-24
5
Frequency detection 2 (ON: Output frequency ≥ +L4-01 or output frequency ≤ -L4-
01, with detection width L4-02 used)
Ye s Yes Ye s 5-24
6
Inverter operation ready
READY: After initialization or no faults
Ye s Yes Ye s 5-47
7 During DC bus undervoltage (UV) detection Yes Yes Yes 5-47
8 During baseblock (NO contact, ON: during baseblock) Yes Yes Yes 5-47
9 Frequency reference source selection (ON: Frequency reference from Operator) Yes Yes Yes 5-47
Setting
Value
Function
Control Methods
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
