YASKAWA Varispeed L7 User Manual

User Parameter Tables
4-19
4
* 1. The unit is set in o1-03 (frequency units of reference setting and monitor, default: 0.01 Hz). If the display unit is changed, the setting range values also
change
* 2. The maximum setting value depends on the setting of the maximum output frequency (E1-04).
Field Weakening: d6
d1-12
V3 reference Sets the frequency reference
when multi-step speed com-
mands 1, 2, and 4 are ON for
multi-function inputs.
0 to
120.00
*1*2
0.00 Hz Yes A A A 28DH 5-7
V3 reference
d1-13
Vr reference Sets the frequency reference
when multi-step speed com-
mands 3 and 4 are ON for
multi-function inputs.
0.00 Hz Yes A A A 28EH 5-7
Vr reference
d1-14
Inspection
reference
Sets the frequency reference
when multi-step speed com-
mands 1, 3, and 4 are ON for
multi-function inputs.
25.00
Hz
Yes Q Q Q 2 8F H 5-7
Inspection
ref
d1-17 Vl reference
Sets the frequency reference
when the leveling reference
selection, FJOG command, or
RJOG command is ON.
4.00 Hz Yes Q Q Q 292H
-
d1-18
Speed
priority
selection
Speed reference priority selec-
tion
0: Use Multi-Speed refer
ence(D1-01-D1-08 )
1: High Speed reference has
priority.
2: Leveling speed reference
has priority.
0 to 2 0 Yes A A A 292H 5-7
Priority Sel
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Display
d6-03
Field forcing
function
selection
Enables or disables field forc-
ing function.
0: Disabled
1: Enabled
0 or 1 0 No No A A 2A2H 5-33
Field Force
Sel
d6-06
Field forcing
function
Limit
Sets the upper limit for the
excitation current applied by
the field forcing function.
A setting of 100% is equal to
the motor no-load current.
Field forcing is active during
all types of operation except
DC Injection.
100 to
400
400% No No A A 2A5H 5-33
Field Force
Lim
Param-
eter
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO-
BUS
Register
Page
V/f
Open
Loop
Vector
Closed
Loop
Vector
Display
