Installing and Wiring Option Cards
Option Card Models and Specifications
Up to two Option Cards can be mounted on the controller card (C and D) shown in Fig 2.16.
Table 2.12 lists the type of Option Cards and their specifications.
Installation
Before mounting an Option Card, remove the terminal cover and be sure that the charge indicator inside the
Inverter is not lit anymore. After that remove the Digital Operator/Monitor and front cover and then mount the
Option Card.
Refer to documentation provided with the Option Card for the mounting instructions for option slot C and D.
Table 2.12 Option Card Specifications
Card Model Specifications
Mounting
Location
DeviceNet
communications card
SI-N1 Option card for DeviceNet fieldbus C
Profibus-DP
communications card
SI-P1 Option card for Profibus-DP fieldbus C
InterBus-S
communications card
SI-R1 Option card for InterBus-S fieldbus C
CANOpen
communications card
SI-S1 Option card for CANOpen fieldbus C
Analog Input Cards
AI-14U
2 channel high resolution analog input card
Channel 1: 0 to 10 V (20 kΩ)
Channel 2: 4 to 20 mA (250 Ω)
Resolution: 14 Bit
C
AI-14B
3 Channel high resolution analog input card
Signal level: -10 to +10 V (20 kΩ)
4 to 20 mA (250 Ω)
Resolution: 13 Bit + sign
C
Digital Input Cards
DI-08 8 bit digital speed reference input card C
DI-16H2 16 bit digital speed reference input card C
Analog Monitor Card
AO-08 8 bit analog outputs, 2 channels D
AO-12 12-bit analog outputs, 2 channels D
Digital Output Card
DO-08 Six photocoupler outputs and 2 relay outputs D
DO-02C 2 relay outputs D
