YASKAWA Varispeed L7 User Manual

4-26
Digital Output Card (DO-02 and DO-08): F5
User constants for the Digital Output Card are shown in the following table.
Con-
stant
Number
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO
BUS
Regis-
ter
Page
Display
V/f
Open
Loop
Vec-
tor
Closed
Loop
Vector
F5-01
Channel 1
output selec-
tion
Effective when a Digital Out-
put Card (DO-02 or DO-08)
is used.
Set the number of the multi-
function output to be output.
0 to 43 0 No A A A 399H -
DO Ch1
Select
F5-02
Channel 2
output selec-
tion
Effective when a Digital Out-
put Card (DO-02 or DO-08)
is used.
Set the number of the multi-
function output to be output.
0 to 43 1 No A A A 39AH -
DO Ch2
Select
F5-03
Channel 3
output selec-
tion
Effective when a DO-08 Dig-
ital Output Card is used.
Set the number of the multi-
function output to be output.
0 to 43 2 No A A A 39BH -
DO Ch3
Select
F5-04
Channel 4
output selec-
tion
Effective when a DO-08 Dig-
ital Output Card is used.
Set the number of the multi-
function output to be output.
0 to 43 4 No A A A 39CH -
DO Ch4
Select
F5-05
Channel 5
output selec-
tion
Effective when a DO-08 Dig-
ital Output Card is used.
Set the number of the multi-
function output to be output.
0 to 43 6 No A A A 39DH -
DO Ch5
Select
F5-06
Channel 6
output selec-
tion
Effective when a DO-08 Dig-
ital Output Card is used.
Set the number of the multi-
function output to be output.
0 to 43 37 No A A A 39EH -
DO Ch6
Select
F5-07
Channel 7
output selec-
tion
Effective when a DO-08 Dig-
ital Output Card is used.
Set the number of the multi-
function output to be output.
0 to 43 0F No A A A 39FH -
DO Ch7
Select
F5-08
Channel 8
output selec-
tion
Effective when a DO-08 Dig-
ital Output Card is used.
Set the number of the multi-
function output to be output.
0 to 43 0F No A A A 3A0H -
DO Ch8
Select
F5-09
DO-08 out-
put mode
selection
Effective when a DO-08 Dig-
ital Output Card is used.
Set the output mode.
0: 8-channel individual out-
puts
1: Binary code output
2: Output according to
F5-01 to F5-08 settings.
0 to 2 0 No A A A 3A1H -
DO-08 Selec-
tion
