Output Terminal Functions
5-49
5
During Regenerative Operation (Setting: 1D)
If a multifunction output is programmed for this function the output is switched ON when the motor works
regenerative, i.e. when energy is feedback to the inverter.
Speed Detection at decelerattion (Door Zone) (Setting:42)
This output can be used to detect, that the car is in the door zone. The detection is speed dependent.
If the Up/Down command is released, this output is switched OFF.
Not Zero Speed (Setting:43)
This function can be used for indicating the reverse condition of Zero speed status.
V/f control and Open Loop Vector control Closed Loop Vector control
OFF
The output frequency is lower than S1-27 during
deceleration
The motor speed is lower than S1-27 during decelera-
tion
ON
The output frequency is higher than S1-27 during
deceleration
The motor speed is higher than S1-27 during deceler-
ation
OFF The output frequency is lower than the zero speed level (b2-01).
ON The output frequency is higher than the zero speed level (b2-01).
