Line Filters
 Recommended Line Filters for Varispeed L7
Maximum Voltage : AC 480V 3phase
Ambient Temperature : 45°C (max.)
* Permissible emission of power drive systems for commercial and light environment (EN61800-3, A11)
(general availability, 1st environment)
Maximum Voltage : AC 240V 3phase
Ambient Temperature : 45°C (max.)
* max. motor cable length: 10 m Class B, 50 m Class A
Rated Voltage: AC240V 3 ph.
Ambient Temperature: 45°C (max.)
Inverter Model Line Filter
Varispeed L7 Model
Current
(A)
Weight
(kg)
Dimensions
W x D x H
CIMR-L7C43P7 FS5972-10-07 10 1.1 141 x 46 x 330
CIMR-L7C44P0
FS5972-18-07 18 1.3 141 x 46 x 330
CIMR-L7C45P5
CIMR-L7C47P5 FS5972-21-07 21 1.8 206 x 50 x 355
CIMR-L7C4011 FS5972-35-07 35 2.1 206 x 50 x 355
CIMR-L7C4015
FS5972-60-07 60 4.0 236 x 65 x 408
CIMR-L7C4018
CIMR-L7C4022
FS5972-70-52 70 3.4 80 x 185 x 329
CIMR-L7C4030
CIMR-L7C4037
FS5972-100-35 100 4.5 90 x 150 x 326
CIMR-L7C4045
CIMR-L7C4055 FS5972-130-35 130 4.7 90 x 180 x 366
Inverter Model Line Filter
Varispeed L7 Model
Current
(A)
Weight
(kg)
Dimensions
W x D x H
CIMR-L7C23P7
FS5973-35-07 35 1.4 141 x 46 x 330
CIMR-L7C25P5
CIMR-L7C27P5
FS5973-60-07 60 3.0 206 x 60 x 355
CIMR-L7C2011
CIMR-L7C2015
FS5973-100-07 100 4.9 236 x 80 x 408
CIMR-L7C2018
CIMR-L7C2022
FS5973-130-35 130 4.3 90 x 180 x 366
CIMR-L7C2030
CIMR-L7C2037 FS5973-160-40 160 6.0 120 x 170 x 451
CIMR-L7C2045
FS5973-240-37 240 11.0 130 x 240 x 610
CIMR-L7C2055
