YOKOGAWA FX103 User Manual

7-18 IM 04L20A01-01E
Operations on the Display
• Deleting files or directories
1. From the directories listed in the [Directory name] box, select the directory in
which the file you wish to delete is located using the up and down arrow keys.
To collectively delete all files in a directory, select the directory and proceed to
step 4. To delete an entire directory, first delete all files in the directory, then
proceed to step 4.
2. Press the right arrow key to move the blue cursor to the file list section.
3. Select the file to be deleted using the up and down arrow keys. To move the
blue cursor back to the [Directory name] column, press the left arrow key.
4. Press the DISP/ENTER key.
A dialog box for confirming the deletion appears.
5. Select [Yes] and press the DISP/ENTER key.
To cancel the operation, select [No] using the right arrow key and press the
DISP/ENTER key.
Note
If the ESC key is pressed in the middle of the operation, the screen returns to the [Save/Load,
Clear Data] menu.
• Formatting the external storage medium
1. Enter the volume name in the [Volume name] box.
The following character strings cannot be used in the volume name.
AUX, CON, PRN, NUL, CLOCK, and strings containing spaces.
If you are not going to set the volume name, move the cursor to the [Type] box
using the down arrow key.
2. Select [Quick] or [Normal] using the soft keys.
3. Press the DISP/ENTER key.
A format confirmation window appears.
4. Select [Yes] and press the DISP/ENTER key.
To cancel the operation, select [No] using the right arrow key and press the
DISP/ENTER key.
Setup Items
Formatting the External Storage Medium
• Type
Select from the following.
Quick: Performs only a logical format.
Normal: Performs a physical format and a logical format.
Disk Format
Floppy disk: 2HD, 1.44 MB
CF memory card: FDISK 1 partition (hard disk format)
Format Time
Type of storage media Quick Normal Note
Floppy disk Approx. 6 s Approx. 1 min. 30 s
CF memory card Approx. 3 s Approx. 1 min. 30 s 32 MB
Approx. 5 s Approx. 6 min. 160 MB
7.7 Managing Files and Checking the Free Space on the External Storage Medium
