Note
• Output value when detected erroneous data, measurement over range data, or computation
overflow data
Channels Data Output value
Measurement channels measurement error Blank
positive (+) over range (including burnout) 99999
negative (–) over range (including burnout) –99999
Computation channels computation error 999999999
positive (+) computation overflow 999999999
negative (–) computation overflow –99999999
• CH/TAG and UNIT lines
In the following cases, both the CH/TAG line and the UNIT line are rewritten after a carriage
return line feed and followed by manual sampled data.
• When the measurement channel is switched from some setting other than [Skip] to [Skip].
• When the measurement channel is switched from [Skip] to some other setting.
• When the computation channels are turned On or turned Off.
• When the unit is changed.
Four lines from the bottom of the file example shows the output when the unit for channel 31
is changed from “mV” to “V.”
