7-4
IM 04P03B01-01E
7.3 Recording Function Specifications
Trend Recording (Pen Model)
Item Specifications
Recording pen Disposable felt pen
Step response time Approx. 1 s (using the IEC61143 measurement method)
Number of pens Up to 4
Recording color Pen 1: Red, pen 2: Green, pen 3: Blue, pen 4: Violet
Trend recording Updates the data at the scan interval. Continuous recording.
Pen offset compensation Records by compensating for the offset of each pen along the time axis.
Chart speed 10 to 12000 mm/h (40 steps).
Zone recording Recording zone can be specified for each channel.
Recording width: 5 mm or more (1 mm steps)
Partial expanded recording Records by expanding the right or left side of the boundary position (the other section is reduced).
Boundary position: 1 to 99%
Boundary value: Within the recording span range
Trend Recording (Dot Model)
Item Specifications
Recording method Trend recording by a 6-color wire dot printer
Recording color Channel 1: Purple, channel 2: Red, channel 3: Green, channel 4: Blue, channel 5: Brown,
channel 6: Black
Trend recording interval Records at the following interval through a raster scan system.
AUTO: Synchronizes to the chart speed and automatically sets to the interval
FIX: 10 s/6 channels
Chart speed 10 to 1500 mm/h (28 steps)
Recording ON/OFF Recording can be turned ON/OFF for each channel.
Zone recording Same as the pen model.
Partial expanded recording Same as the pen model.
Chart Paper
Item Specifications
Printing width 100 mm
Type/Length Z-fold type. Approx. 16 m.
Chart paper feeding accuracy
Within ±0.1% After feeding 1000 mm and with respect to the print scale on the chart paper.
