YOKOGAWA SR10000 series User Manual

1-23
IM 04P03B01-01E
Functional Explanation and Setup Guide
1
1.6 Function Setup Guide
This section explains the settings necessary to use various functions of the recorder.
Read the section corresponding to the function you wish to use.
Note
This section contains all the settings related to each item. If the desired setting is the same as
the default value, you do not have to set it.
Item Description Reference
Section
Date/Time setting Use CLOCK in Setting mode 2.5
DST Sets the date/time for switching between DST and standard time using 3.14
AUX > DST in Setting mode.
Setting initialization Use INIT in Basic Setting mode to initialize the settings of Setting mode 4.17
and Basic Setting mode to their default values.
Measuring input functions
Item Description Reference
Section
Range and span of the TC, RTD, or DC voltage
Use RANGE in Setting mode. 2.1
1-5V • Range, span, and scale 2.1
Use RANGE in Setting mode.
• Unit 2.3
Use UNIT in setting mode to set the unit after scaling.
• Low-cut 4.15
Use PERS. > 1-5V low-cut in Basic Setting mode and select Use or Not.
If Use is selected, turn ON/OFF the low-cut function using RANGE in Setting 2.1
mode.
If Not is selected, the Low-cut item does not appear in the RANGE setting.
Scaling • Range, span, and scale 2.1
Use RANGE in Setting mode.
• Unit 2.3
Use UNIT in setting mode to set the unit after scaling.
Square Root Computation • Range, span, and scale 2.1
Use RANGE in Setting mode.
• Unit 2.3
Use UNIT in setting mode to set the unit after scaling.
• Low-cut 4.15
Use PERS. > SQRT low-cut in Basic Setting mode and select Use or Not.
If Use is selected, set the low-cut value using RANGE in Setting mode. 2.1
If Not is selected, the Low-cut item does not appear in the RANGE setting.
Unused channels Use RANGE > SKIP in Setting mode to disabling the trend recording (dot model) 2.1
and periodic printout of the target channel.
Bias Use PERS. > BIAS in Basic Setting mode and select Use or Not. 4.15
If Use is selected, set the bias value that is added to the input using BIAS in 3.10
Setting mode. If Not is selected, the BIAS item does not appear.
Calibration Correction (/CC1 option)
Use PERS. > CALIB in Basic Setting mode and select Use or Not 4.15
If Use is selected,
• Use CALIB in Basic Setting mode to set the correction mode and the number 4.22
of calibration points.
• Use CALIB in Setting mode to set the measured value and correction value 3.11
for each channel.
If Not is selected, the CALIB item does not appear.
Burnout detection function (TC input and 1-5V input) 4.3
Use B_OUT in Basic Setting mode to set the burnout detection function for each
channel.
