YOKOGAWA SR10000 series User Manual

7-13
IM 04P03B01-01E
Specifications
7
7.6 General Specifications
Construction
Item Specifications
Mounting Flush panel mounting (on a vertical plane)
Mounting angle Inclined backward up to 30 degrees from a horizontal plane.
Allowable panel thickness 2 to 26 mm
Material Case: drawn steel
Front door: Aluminum die-cast
Color Case: Charcoal gray light (Munsell 10B3.6/0.3 or equivalent)
Front door: Charcoal gray light (Munsell 10B3.6/0.3 or equivalent)
Front panel Water and dust-proof (complies with DIN40050-IP54)
Dimensions 144(W) × 144(H) × 220(D) mm (D: depth from the panel mounting plane)
Weight 1-pen: approx. 2.1 kg, 2-pen: approx. 2.2 kg, 3-pen: approx. 2.3 kg, 4-pen: approx. 2.4 kg
6-dot: approx. 2.5 kg
Normal Operating Conditions
Item Specifications
Ambient temperature 0 to 50°C
Ambient humidity 20 to 80%RH (at 5 to 40°C)
Allowable power supply voltage range
90 to 132, 180 to 264 VAC
Power supply frequency 50 Hz ±2%, 60 Hz ±2%
Vibration 10 to 60 Hz 0.2 m/s
2
or less
Shock Not acceptable.
Magnetic field 400 A/m or less (DC and 50/60 Hz)
Noise Normal mode (50/60 Hz)
Volt: The peak value including the signal must be less than 1.2 times the rated value of the range
(Example: 2 V for 2 V range).
TC: The peak value including the signal must be less than 1.2 times the rated value of the range.
RTD: 50 mV or less
Common mode noise (50/60 Hz): 250 VACrms or less for all ranges
Maximum noise voltage between channels (50/60 Hz): 250 VACrms or less.
Mounting position Up to 30° of backward tilt angle allowed, no tilt to the left or right
Warm-up time At least 30 minutes after power on
Altitude 2000 m or less above sea level
Power Supply
Item Specifications
Rated supply voltage 100 to 240 VAC
Allowable power supply voltage range
90 to 132, 180 to 264 VAC
Rated power supply frequency
50 Hz, 60 Hz
Rated power 40 VA
Power consumption
Model 100 VAC 240 VAC Maximum
1- to 4-pen model Approx. 12 VA* Approx. 17 VA* Approx. 40 VA
6-dot model Approx. 13 VA* Approx. 18 VA* Approx. 40 VA
* When balanced
