5-1
IM 04P03B01-01E
Troubleshooting
5
5.1 A List of Error Messages
There are cases in which the LED displays an error code during operation. The error
messages and their description are listed below.
Setting Errors
Code Message Sent via Communication Explanation/Countermeasures
001 System error. Contact your nearest YOKOGAWA dealer.
002 Incorrect date or time setting. Check the setting.
003 A disabled channel is selected. The channel does not exist.
004 Incorrect function parameter. Incorrect communication parameter.
005 The input numerical value exceeds the set range. –
006 Incorrect input character string. The entered character cannot be used.
007 Too many characters. –
008 Incorrect input mode. Incorrect range mode (Volt, TC, Scale, etc.) setting.
009 Incorrect input range code. Incorrect range type (2 V, R, PT100, etc.) setting.
010 Format error. Incorrect character string format.
011 Range settings are not same within the selected Channels whose range differs cannot be set simultaneously.
channels.
012 An invalid characters. Contains an invalid character.
013 Ref. CH error. Specify a channel whose range is set to voltage, TC, or RTD for
the reference channel.
015 Too many characters for printout. Too many characters in the message printout including measured
values.
016 Too many characters for message. Cannot enter a setting that exceeds the message string (16
characters).
021 Cannot set an alarm for a SKIPPED channel. –
022 The upper and lower span limits are equal. This is not allowed.
023 The upper and lower scale limits are equal. This is not allowed.
024 The lower span limit is greater than the upper span –
limit.
025 The lower scale limit is greater than the upper scale –
limit.
026 Bias cannot be set to the SKIPPED channel. –
027 Bias cannot be set to the DI channel. –
030 The partial boundary value exceeds the range of the –
span.
031 Partial is invalid on the SKIPPED channel. –
035 The upper and lower limits of the printing zone Set the rightmost value of the zone – the leftmost value ≥ 5
are equal. mm.
036 The lower limit of the printing zone is greater Set the rightmost value of the zone – the leftmost value ≥ 5
than the upper limit. mm.
037 The printing zone is narrower than the minimum Set the rightmost value of the zone – the leftmost value ≥ 5
width (5 mm). mm.
038 Partial is invalid on the DI channel. –
039 The bias and the calibration cannot be used –
simultaneously.
040 Datume value (1 >= 2) Set the measured value of the first point less than that of the
second point in the calibration correction.
041 Datume value (n-1 > n) Set the measured value of the n–1
th
point less than or equal to
that of the n
th
point in the calibration correction.
042 Revise value (n-1 >= n) Set the correction value of the n–1
th
point less than that of the n
th
point in the calibration correction.
Chapter 5 Troubleshooting
To Next Page
