4-35
IM 04P03B01-01E
Setup Operations for Changing/Adding Functions (Basic Setting Mode)
4
4.23 Enabling Start Printout, End printout, and
Message Format (/BT1 Option)
This section explains the details of enabling/disabling the Start printout, End printout, and
Message format.
Basic Setting mode cannot be entered when recording is in progress .
Procedure
1. Hold down the
MENU
key for 3 seconds to enter Setting mode.
2. Hold down the and keys simultaneously for 3 seconds to display the
Basic Setting mode screen.
3. Carry out the procedure shown in the figure below.
Press the
or key to select the value.
If you press the key, the operation is cancelled, and the display returns to a
higher level menu.
Select “BATCH.”
(BATCH)
(USE)
(LOT)
(DUAL)
(USE)
(MSG_F)
(USE)
(OK)
The settings are activated.
Start printout and End printout
Select to enable (USE) or disable (NOT).
(Only when Start printout and End printout
are enabled)
Lot number
Select 4 digits, 6 digits, or disable (NOT).
(Only when Start printout and End printout
are enabled)
Dual comment
Select to use Start printout 2 and
End printout 2.
Message format
Select to enable (USE) or disable (NOT).
4. Press the key to set other channels.
If you are done, press the key.
5. To return to the Operation mode,
1. Press the
key, use the or key to select , and press the
key.
2. Press the or key to select or , and press the
key.
To Next Page
