YOKOGAWA SR10000 series User Manual

1-24
IM 04P03B01-01E
Item Description Reference
Section
RJC of TC input Use RJC in Basic Setting mode to select whether to use the internal 4.4
RJC function or an external RJC function.
Filter (pen model) Use FILTR in Basic Setting mode and select Use or Not. 4.11
If Use is selected, set the filter time constant using AUX > FILTR in Setting mode. 3.2
If Not is selected, the AUX > FILTR item does not appear.
Moving average (dot model)
Use M_AVE in Basic Setting mode and select Use or Not. 4.10
If Use is selected, set the number of samples of moving average using AUX > 3.3
M_AVE in Setting mode.
If Not is selected, the AUX > M_AVE item does not appear.
Integration time of the A/D converter 4.2
Use INTG in Basic Setting mode to set the integration time of the A/D converter.
Temperature Unit Select the temperature unit using TEMP in Basic Setting mode. 4.24
Alarm functions
Item Description Reference
Section
Alarms for each channel Use ALARM in Setting mode. 2.2
Set a hysteresis on the alarm occurrence/release value of high limit alarm and low limit alarm
Use ALARM > HYS in Basic Setting mode to set the hysteresis to be applied 4.1
to the high limit alarm and low limit alarm of measurement channels.
Diagnosis output Use ALARM > DIAG in Basic Setting mode to set the function. 4.1
Change the alarm output relay operation
If ALARM > RELAY in Basic Setting mode set to “DE_EN”, alarm output relay is 4.1
energized during normal operation and de-energized when an alarm occurs.
Recording functions
Item Description Reference
Section
Recording interval (dot model)
Use AUX > TREND in Setting mode to set the recording interval to AUTO or FIX. 3.1
Change the recording color of measurement channels (dot model).
Use COLOR in Basic Setting mode to set the recording color of measurement 4.5
channels.
Turn trend recording ON/OFF (dot model)
Use AUX > PRINT in Setting mode to turn ON/OFF the trend recording for each 3.6
measurement channel.
Chart speed Use CHART in Setting mode to set the chart speed. 2.4
Record by setting recording zone
Use AUX > ZONE in Setting mode to set the recording zone for each channel. 3.4
Partial expanded recording Use PART in Basic Setting mode and select Use or Not. 4.12
If Use is selected, set the display mode using AUX > PART in Setting mode. 3.5
If Not is selected, the AUX > PART item does not appear.
Record by compensating for the pen offset along the time axis (pen model)
Use POC in Setting mode to turn ON/OFF offset compensation. 4.6
Date format Use DATE in Basic Setting mode to set the printout/display format 4.14
of the date.
Time format Use T_PRN in Basic Setting mode to set the printout format of the time. 4.16
1.6 Function Setup Guide
