YOKOGAWA SR10000 series User Manual

7-10
IM 04P03B01-01E
Green Display (/D6)
Item Specifications
Color 1
st
digit (channel display) and 3
rd
to 7
th
digits (data display) of the 7- segment LED: Green
2
nd
digit (alarm display): Orange
Cu10, Cu25 RTD Input (/N1)
Item Specifications
Cu10, Cu25 RTD This option allows Cu10 and Cu25 inputs to be added to the standard input types.
Input type and measurable range
Input Type
Measurable Range
RTD
(Measurement
current i: 2 mA)
Cu10 (GE)
Cu10 (L&N)
Cu10 (WEED)
Cu10 (BAILEY)
Cu10: α = 0.00392 at 20°C
Cu10: α = 0.00393 at 20°C
Cu25*: α = 0.00425 at 0°C
–200 to 300°C
–328.0 to 572.0°F
* Measurement current i = 1 mA
Measurement and recording accuracy
Cu10 (GE)
Cu10 (L&N)
Cu10 (WEED)
Cu10 (BAILEY)
Cu10: α = 0.00392 at 20°C
Cu10: α = 0.00393 at 20°C
Cu25: α = 0.00425 at 0°C
Measurement Accuracy
Recording Accuracy
Measurement accuracy
± (0.3% of recording span)
±(0.4% of rdg + 1.0°C)
±(0.3% of rdg + 0.8°C)
Input Type
Expansion Inputs (/N3)
Item Specifications
Input type Adds the input types shown in the table below.
Input Type Measurement Range
PR40-20 0.0 to 1900.0°C 32 to 3452°F
PLATINEL 0.0 to 1400.0°C 32 to 2552°F
Thermocouple NiNiMo 0.0 to 1310.0°C 32 to 2390°F
W/WRe26 0.0 to 2400.0°C 32 to 4352°F
Type N (AWG14) 0.0 to 1300.0°C 32 to 2372°F
Kp vs Au7Fe 0.0 to 300.0 K
Pt25 –200.0 to 550.0°C –328.0 to 1022.0°F
Pt50 –200.0 to 600.0°C –328.0 to 1112.0°F
Ni100 (SAMA) –200.0 to 250.0°C –328.0 to 482.0°F
RTD Ni100 (DIN) –60.0 to 180.0°C –76.0 to 356.0°F
(Measuring current Ni120 –70.0 to 200.0°C –94.0 to 392.0°F
i = 1 mA) J263*B 0.0 to 300.0 K
Cu53 –50.0 to 150.0°C –58.0 to 302.0°F
Cu100:
α = 0.00425 at 0°C –50.0 to 150.0°C –58.0 to 302.0°F
7.5 Specifications of Optional Functions
